GPU Engine Specs
CUDA Cores
– 10752
Boost Clock (MHz)
– 2640 MHz
Base Clock (MHz)
– 2295MHz
Thermal and Power Spec
Minimum System Power Requirement (W)
– 850W
Supplementary Power Connectors
– 3x PCIe 8-pin cables (adapter in box) OR 1x 450 W or greater PCIe Gen 5 cable
Memory Specs
Memory Clock
– 30Gbps
Standard Memory Config
– 16GB
Memory Interface
– GDDR7
Memory Interface Width
– 256-bit
Memory Bandwidth (GB/sec)
– 960 GB/sec
Feature Support
Real-Time Ray Tracing
– Yes
Ray Tracing Cores
– 4th Generation, 171 TFLOPS
Tensor Cores
– 5th Generation, 1801 AI TOPS
NVIDIA Architecture
– Blackwell
Microsoft DirectX
– 12 Ultimate
NVIDIA DLSS
– 4
NVIDIA Ansel
– Yes
NVIDIA FreeStyle
– Yes
Bus Support
– PCI Express Gen 5
NVIDIA ShadowPlay
– Yes
OS Certification
– Windows 11 / 10, Linux, FreeBSDx86
NVIDIA Highlights
– Yes
NVIDIA G-SYNC™-Ready
– Yes
Game Ready Drivers
– Yes
NVIDIA Studio Drivers
– Yes
NVIDIA GPU Boost™
– Yes
Vulkan API
– 1.4
OpenGL
– 4.6
NVIDIA Encoder
– 2x Ninth Generation
NVIDIA Decoder
– 2x Sixth Generation
Graphics Card Dimensions
Length
– 300mm
Height
– 120mm
Width
– 50mm
Display Support
Multi Monitor
– up to 4
Maxmium Digital Resolution
– 4K at 480Hz or 8K at 165Hz with DSC
HDCP
– 2.3
Standard Display Connectors
– 3x DisplayPort 2.1b, 1x HDMI 2.1b
